| Parameter | Specification / Value |
| Transport Length | 2200 mm |
| Total Width B | 925 mm |
| Total Height C | 1520 / 2150 mm |
| Platform Width D | 805 mm |
| Chassis Total Width E | 925 mm |
| Track Width F | 180 mm |
| Wheelbase G | 906 mm |
| Track Gauge H | 742 mm |
| Platform Ground Clearance I | 370 mm |
| Max. Digging Height A | 2500 mm |
| Max. Dumping Height B | 1700 mm |
| Max. Digging Depth C | 1700 mm |
| Max. Digging Radius E | 2900 mm |
| Min. Swing Radius F | 1450 mm |
| Standard Engine Brand | Koop 192F |
| Emission Standard | National II (China II) |
| Engine Power | 8 kW / 3600 RPM |
| Standard Bucket Width | 400 mm |
| Bucket Capacity | 0.025 $m^3$ |
| Optional Engines | Changchai, Koop, Briggs & Stratton, Lithium Battery, Electric Motor |
ZM12 Mini Excavator: High-Efficiency 1.2-Ton Compact Workhorse
Greater Dig Depth, Enhanced Stability, and Maximum Productivity
The ZM12 Mini Excavator is a versatile 1.2-ton class compact digger designed for contractors, utilities, and rental companies requiring higher digging capacity without sacrificing tight-space maneuverability. Engineered with a wider 925 mm chassis and reinforced 180 mm rubber tracks, the ZM12 offers outstanding operating stability and traction across uneven terrain, mud, and hard clay.
With a powerful hydraulic system delivering an extended 1700 mm maximum digging depth and a wide 2900 mm digging radius, the ZM12 effortlessly handles deeper utility trenching, foundation footing, and heavy-duty landscaping tasks that smaller micro diggers struggle to complete.
Key Performance Highlights
1. Superior 1700mm Digging Depth & Working Reach
The ZM12 provides a major performance upgrade with a 1700 mm digging depth and 2900 mm digging radius. Combined with a wider 400 mm standard bucket (0.025 m³ capacity), it moves significantly more earth per cycle, drastically reducing project completion time.
2. Enhanced Chassis Stability (925mm Total Width)
With a widened 925 mm chassis total width and a sturdy 742 mm track gauge, the ZM12 delivers balanced weight distribution and high side-stability. This allows operators to run heavier attachments—like hydraulic breakers and augers—with complete safety and reduced tipping risks.
3. Dual-Height Protection Frame (1520mm / 2150mm)
Equipped with a sturdy safety canopy/ROPS frame reaching 2150 mm, the operator remains protected on active construction sites. For low-clearance transport or working under low branches/carports, the canopy height drops down to 1520 mm.
4. Versatile Engine Options for Global Compliance
Choose from multiple reliable powertrains to match local emission laws and site preferences:
- Standard Diesel: Single-cylinder air-cooled Koop 192F / Changchai engine delivering 8 kW of continuous output.
- EPA / Euro V Certified: Premium Briggs & Stratton gasoline engine options designed for strictly regulated markets in North America and Europe.
- Zero-Emission Electric: Optional Lithium Battery or Pure Electric Motor setups, offering 100% emission-free and low-noise operation for indoor or eco-sensitive job sites.
Key Applications
- Deep Utility Trenching: Easily digs down to 1.7 meters for deep water pipes, sewer lines, and power trunk cables.
- Foundation & Footing Work: Excellent for excavating post footings, retaining wall foundations, and patio bases.
- Landscape Construction: Clearing heavy roots, grading soil, moving rocks, and digging irrigation ponds.
- Rental Fleets & Fleet Contractors: A high-demand, rugged 1.2-ton machine that balances compact size with high rental ROI.
Compatible Quick-Change Attachments
Maximize machine utilization with quick-hitch attachments:
- Hydraulic Breaker Hammer: Perfect for cracking asphalt, paving stones, and concrete.
- Earth Augers: For fence post installation, solar panel pile driving, and tree planting.
- Hydraulic / Mechanical Thumb: Easily grab logs, rocks, and demolition debris.
- Rake & Heavy Ripper: Tear through tough soil, frozen ground, and dense roots.
- Bucket Options: 200mm trenching, 400mm standard, and 800mm wide grading/tilting buckets.
Frequently Asked Questions (FAQ)
Q1: How does the ZM12 compare to the ZM08 and ZM09 models?
The ZM12 is built on a wider 925mm chassis with 180mm tracks, offering significantly higher lateral stability, a deeper 1700mm digging depth, a longer 2900mm reach, and a larger 400mm bucket compared to the narrower ZM08/ZM09 models.
Q2: Can the ZM12 canopy be folded or removed for transport?
Yes. The upper protection canopy/ROPS frame is designed for quick adjustment, reducing the machine’s overall height from 2150 mm down to 1520 mm for low-clearance transport or storage in standard utility trailers.
Q3: Are zero-emission or Euro V / EPA compliant engines available?
Yes, we supply Briggs & Stratton gasoline engines meeting EPA Tier 4 and Euro V standards, as well as Lithium-ion Battery / Electric Motor options for low-noise and zero-emission operations.
