| Parameter | Specification / Value |
| Transport Length | 2500 mm |
| Total Width B | 720 mm |
| Total Height C | 1300 mm |
| Platform Width D | 700 mm |
| Chassis Total Width E | 720 mm |
| Track Width F | 150 mm |
| Wheelbase G | 860 mm |
| Track Gauge H | 550 mm |
| Platform Ground Clearance I | 350 mm |
| Max. Digging Height A | 2800 mm |
| Max. Dumping Height B | 1880 mm |
| Max. Digging Depth C | 1400 mm |
| Max. Digging Radius E | 2330 mm |
| Min. Swing Radius F | 730 mm |
| Standard Engine Brand | Koop 192F |
| Emission Standard | National II (China II) |
| Engine Power | 8 kW / 3600 RPM |
| Standard Bucket Width | 300 mm |
| Bucket Capacity | 0.02 $m^3$ |
| Optional Engines | Changchai, Koop, Briggs & Stratton, Lithium Battery, Electric Motor |
ZM09 Mini Excavator: Ultra-Narrow 1-Ton Micro Digger for Tight Spaces
Maximum Reach and Maneuverability in Restricted Job Sites
The ZM09 Mini Excavator is an ultra-compact 1-ton class micro digger engineered specifically to solve space-constraint challenges. Combining an ultra-narrow 720mm overall width with a compact 730mm minimum swing radius, the ZM09 effortlessly passes through standard residential doorways and tight side-gates, enabling fully mechanized operations where larger machines cannot enter.
Despite its compact footprint, the ZM09 boasts an impressive 2800 mm maximum digging height and a 1400 mm digging depth, making it an unbeatable choice for indoor demolition, utility trenching, municipal pipe installation, and residential landscaping.
Key Performance Advantages
1. Ultra-Narrow 720mm Chassis & Compact 730mm Swing Radius
With a total width of only 720 mm and a tail swing radius of just 730 mm, the ZM09 excels at operating close to walls, fences, and structural obstacles. It virtually eliminates collision risks when rotating in tight hallways or confined backyards.
2. High-Reach Hydraulic Geometry
Featuring an optimized boom and arm design, the ZM09 achieves a 2800 mm max digging height and an 1880 mm dumping height. This allows operators to easily load high-sided trailers or dump trucks with minimal effort.
3. Customizable Powertrain Configurations
To comply with local emission regulations and job site demands, the ZM09 supports multiple drive options:
- Standard Diesel: Single-cylinder Koop 192F / Changchai engines delivering reliable 8 kW power and excellent fuel economy.
- EPA / Euro V Certified: Premium Briggs & Stratton gasoline engine upgrades for strict North American and European regulatory standards.
- Zero-Emission Electric Options: Available with Lithium Battery or Pure Electric Motor drives—ideal for indoor demolition and noise-sensitive residential night operations.
4. Compact & Easy Logistics
With its short 2500 mm transport length and lightweight profile, the ZM09 can be easily loaded onto standard light trailers or towed inside small vans, drastically reducing site-to-site transport costs.
Technical Specifications
| Category | Parameter / Feature | Specification Value |
| Overall Dimensions | Transport Length | 2,500 mm |
| Total Width (B) | 720 mm | |
| Total Height (C) | 1,300 mm | |
| Platform Width (D) | 700 mm | |
| Chassis Total Width (E) | 720 mm | |
| Track Width (F) | 150 mm | |
| Wheelbase (G) | 860 mm | |
| Track Gauge (H) | 550 mm | |
| Platform Ground Clearance (I) | 350 mm | |
| Operating Range | Max. Digging Height (A) | 2,800 mm |
| Max. Dumping Height (B) | 1,880 mm | |
| Max. Digging Depth (C) | 1,400 mm | |
| Max. Digging Radius (E) | 2,330 mm | |
| Min. Swing Radius (F) | 730 mm | |
| Engine & Power | Standard Engine Brand | Koop 192F (Air-Cooled Diesel) |
| Emission Standard | National II (China II) / Optional Euro V & EPA | |
| Engine Power | 8 kW @ 3600 RPM | |
| Optional Powertrains | Changchai, Koop, Briggs & Stratton, Lithium Battery, Electric Motor | |
| Bucket & Work Device | Standard Bucket Width | 300 mm |
| Bucket Capacity | 0.02 m³ |
Target Applications
- Indoor Demolition & Renovation: Fits easily through exterior doors to break concrete slabs and strip interiors.
- Narrow Garden & Landscaping: Drive through narrow side gates without damaging lawn structures or garden walls.
- Trenching & Pipe Laying: Efficient for laying broadband fiber, electric cables, and drainage pipes along property lines.
- Farm & Greenhouse Work: Navigate tightly spaced greenhouse rows and livestock pens with zero clearance issues.
Compatible Quick-Hitch Attachments
- Hydraulic Breaker Hammer: For concrete and pavement breaking.
- Earth Auger Drives: For post-hole drilling and tree planting.
- Ripper & Rake: For tearing through roots and hard-packed clay.
- Mechanical / Hydraulic Thumb Clip: For picking up rocks, logs, and demolition debris.
- Bucket Options: 200mm narrow trenching buckets and 600mm wide grading buckets.
Frequently Asked Questions (FAQ)
Q1: Can the ZM09 micro excavator fit through a standard doorway?
Yes. With an overall width of 720 mm, the ZM09 is built to pass through standard doors (typically 800mm–900mm wide) without removing frame structures.
Q2: What is the main advantage of the 730mm minimum swing radius?
The 730 mm swing radius minimizes the rear overhang during operation. This allows operators to swing and dump material in tight alleys or against building walls without hitting surrounding barriers.
Q3: Are EPA / Euro V certified engine options available for European and US markets?
Yes, we offer Briggs & Stratton gasoline options that meet EPA and Euro V regulations, as well as Lithium-ion Battery / Electric Motor options for 100% zero-emission requirements.
